Month: May 2010

Reload last model

Option available to reload automatically last model used when opening GiD. This option can be activated in the preferences window. Just go from the top menu to Utilities->Preferences, select the  General->Other branch and check the Reload last model option.

How to select entities with filters

Anytime user is making a selection inside GiD (geometry or mesh entities), the selection window can be used to apply useful filters to the selection. This option can be activated in preprocess mode selecting the menu Utilities->Tools->Selection window. It can also be activated from the contextual menu, clicking with the right mouse button.

Rotate, Pan, Zoom With Mouse

Rotate, pan and zoom are accessible directly from mouse buttons, pressing shift key. User can access to rotate, pan and zoom view options directly using mouse buttons, while the shift key is pressed: shift + left mouse button -> ROTATE shift + wheel/center mouse button -> ZOOM shift + right button -> PAN

LS-DYNA Interface

GiD LS-DYNA Graphical Interface is an application acting as a bridge between the pre/post processing program GiD and the commercial nonlinear dynamic solver LS-DYNA. LS-DYNA is a general purpose finite element code used to analyze the large deformation response of structures (including structures coupled to fluids). Specialized capabilities for airbags, sensors and seatbelts have tailored …

LS-DYNA Interface Read More »

Nastran Interface

NASTRAN Interface: Statics and dynamic interface for NASTRAN analysis program. Supports MSC/NASTRAN, NE/NASTRAN and MI/NASTRAN The NASTRAN problem type is designed to be a bridge between NASTRAN codes and the GiD pre/postprocessor. NASTRAN Interface uses the power tools of GiD mesh and the easy way to assign conditions directly over geometry. With these special capabilities, …

Nastran Interface Read More »

Abaqus Interface

GiD-Abaqus Interface allows the user to pre and postprocess Abaqus problems in a single and completely graphical environment, thanks to the powerful tools of GiD. Geometry can be directly created with the GiD CAD tools or imported and repaired thanks to a standard format (please refer to the GiD manual in order to get more …

Abaqus Interface Read More »

Ansys Interface

ANSYS interface: Problem types Ansys55_plane.gid and Ansys55_3D.gid permit to define the model to analyze inside GiD and transfer the data to Ansys, where the analysis is automatically performed. The type of analysis that can be done for all problems is linear elastic. Click here for download and installation instructions
